- 36 -
not over 120℃, and you can close the bed above 100mm except printing ABS
or other high-temperature required filaments.
3. The model not stick on the platform ?
Please paste masking paper or Kapton tape on the platform, or the nozzle is
too far away from the platform, or the bottom of the model is not flat.
4. No or less silk coming on the first layer ?
The distance between nozzle and platform is too small, or the filament has not
been sent to the nozzle.
5. Why nozzle is not spit silk ?
The filament is not pressed or too tight, or print temperature is too low, or the
filament feeder not working.
6. How to prevent model become warped ?
Increase hot bed temperature or use Kapton, or change platform adhesion
type to Raft, or cover the baffle, or reduce indoor ventilation.
7. How far from nozzle to platform appropriate ?
Distance should be 0 in theory, but there is no absolutely flat platform, so the
distance should +-0.1mm. Finally, with the actual printing effect as the
standard, too close will lead to a silk blocked, too far will cause the model not
stick on the platform.
8. How to determine whether the temperature is too high ?
PLA temperature is too high will appear liquefaction, ABS will be the carbide,
that will block the nozzle.
9. What reasons will causing nozzle blocked ?
Filament are impurities or print environment dust too much, bad of thermal
conductivity between the nozzle and the heating block.
10. Model surface is loose with crack ?
The layer is too high or the printing speed too fast, nozzle temperature too
low or filament press nut too loose, or filament is wrapped.
11. How to print a small model ?
Multiple the model, and print them at a time.
12. Dual color model not aligned ?
Adjust offset of second nozzle in machine settings.
13. Dual color model color interference ?
Align two nozzle in vertical direction
14. There is too much silk drag on the model ?
Please enable filament retraction, and specified proper retract speed, and
distance, the retract distance should not less than 4mm, and the speed not
less than 10mm/s.
Printing Troubleshoot
- 37 -
SpecificationsSpecifications
0.4mm(0.3/0.6/0.8/1.0mm can be customized)
120mm/s (inner/outter, top/bottom, fill, first layer speed can be set separately)
ABS,PLA,TPU,PETG,HIPS,PVA, PA,PC,Carbon Fibre,PEEK,etc
Yes (pwr manager + relay)
Yes (Power outage, lower plate and save data)
Yes (pause printing when filament finish, and lower platform)
Yes (height-adjustable-nozzles)
Windows, Linux, Mac OS, OSX
Chinese, English multi-language
4.3 inches color touch screen
