MOUNTING BRACKET ATTACHMENT
• The outlet box and beam must be securely mounted and capable of reliably supporting at
least the weight of the fan.
Wood roof
Securely attach the mounting bracket with
wood screws and washers to the ceiling joints.
Concrete ceiling
Drill holes with an 8mm drill, depending on
the length of the expansion screws. Next,
secure the mounting bracket to the ceiling
with the expansion screws.
Do not x the mounting bracket directly on ceilings less than 10mm thick to avoid the risk of
the screw loosening.
1. **Light
2. On / off button
3. Fan intensity control
4. Timer
5. Batteries (2 x AAA)
6. **Color temperature control
7. **Fan intensity control
8. Inverse function
REMOTE CONTROL
** Function only available
when the LED board is
installed.
