Technical Specifications
E-MU Systems 32
Analog Line Outputs (2)
Type: unbalanced, AC-coupled, 2-pole low-pass differential filter
D/A converter: CS4392
Level: Consumer: +6.8dBV max (unbalanced)
Frequency Response: (20Hz - 20kHz) 0.00/-.07dB
Dynamic Range: (1kHz, A-weighted) 112dB
Signal-to-Noise Ratio: (A-weighted) 112dB
THD+N: (1kHz at -1dBFS) -98dB (.0013%)
Stereo Crosstalk: (1kHz at -1dBFS) < -110 dB
Headphone Amplifier
Type: Class-A power amplifier
D/A converter: CS4392 (shared with Line Out)
Gain Range: 60dB
Maximum Output Power: 16mW
Output impedance: 22ohms
Frequency Response: (20Hz–20kHz) +0.02/-0.08dB
Dynamic Range: (A-weighted) 110dB
Signal-to-Noise Ratio: (A-weighted) 108dB
THD+N: (1kHz, max gain): 300ohm load -98dB (.0013%)
Stereo Crosstalk: (1kHz at -1dBFS, 300 ohm load) < -91dB
Dimensions / Weight
Weight: 0.94 lb / 0.43 kg
Dimensions:
W: 6.5” H: 2.0” L: 5.5”
W: 165 mm H: 50.8 mm L: 140 mm
