Creative audigy 5 - Music Creation Setup

Creating Music
You can set up a home music studio using your Sound Blaster Audigy 5.
Put together your own productions consisting of multiple music tracks from a MIDI Synthesizer, an
electric guitar or a microphone. Alternatively, connect your electric guitar using a Pre-amp Box to the
Line In jack. Use a convertor if your electric guitar comes with a larger connector.
OPTICAL OUT
MIC 1
MIC 2
LINE IN
FRONT
REAR/
SIDE R
SUB/
C/SIDE L
1
2
Jack, Connector or Cable Description
1. Mic In jack Connects to a microphone.
2. Line In jack
Connects to line sources (for
example, electric guitars).
Connecting Related Peripherals 9
