Creative Sound Blaster X-Fi Notebook User Manual

Connecting your MD recorder
Creating Music
You can set up a home music studio using your Sound Blaster X-Fi Notebook.
Put together your own productions consisting of multiple music tracks from a MIDI Synthesizer or an
electric guitar. Alternatively, connect your electric guitar using a Pre-amp Box to the Microphone In/Line In
jack (3.50 mm or 1/8-inch jack). Use a convertor if your Pre-amp Box comes with a larger connector, for
example, a 6.35 mm (1/4-inch) connector.
2.
3.50mm (1/8-inch) stereo-to-RCA cable
(available separately)
Connects the recording device to your Sound Blaster X-Fi
Notebook.
3. Line In jacks
Connects to the Headphone/Line Out jack on your Sound
Blaster X-Fi Notebook.
Connectivity or Features Description
1. Headphone/Line Out jack Connects to the Line In jack on your recording device.
2.
2 channel audio cable (available
separately)
Connects the recording device to your Sound Blaster X-Fi Notebook.
3. Line In jack
Connects to the Headphone/Line Out jack on your Sound Blaster X-
Fi Notebook.
Page
14
of
19
