Creator C50X Single vehicle & OBDII Scanner
7
3. C50X series Model description
Model
Support vehicle
C501
BMW & OBDII/EOBD
C502
BENZ & OBDII/EOBD
C507
HONDA/ACURA & OBDII/EOBD
C508
FIAT & OBDII/EOBD
…
…
4. Software Function
CATION: Don’t connect or disconnect any test
equipment with ignition on or engine running.
1) Turn the ignition off.
2) Locate the vehicle’s 16-pin Data Link
Connector (DLC)
3) Plug into the scan tool cable connector to the
vehicle's DLC ，the scan tool will be light.
As shown
4) Turn the ignition on. Engine can be off or
running
