4.4.3 Command List
The following table shows command list.
Command Code Function
Dispensing card
(Card-out address)
‘’(0x44 0x43) Dispensing card out of
the bezel
Enquiry ‘’(0x41 0x50) Check the status of
dispenser
Reset ‘RS’0x52 0x53) Reset command
Pre-dispensing valid ‘IP’0x49 0x50 Permit card
pre-dispensing
Pre-dispensing invalid ‘IE’ (0x49 0x45) Forbid card
pre-dispensing
Baud rate setting ‘B0’ (0X42 0X30)
‘B1’(0X42 0X31)
‘B2’(0X42 0X32)
‘B3’(0X42 0X33)
‘B4’(0X42 0X34)
‘B5’(0X42 0X35)
‘B0’:1200baud
‘B1’:2400baud
‘B2’:4800baud
‘B3’:9600baud
‘B4’:19200baud
‘B5’:38400baud
4.4.4 Working Status Response Datasheet
The following table shows working status response datasheet.
Status Code Specification
Dispenser is ready ‘0’(0x30) Response this status while
dispenser is waiting for command
Dispenser dispensing
card
‘1’(0x31) Response this status while
dispensing card
Last dispensing
success
‘3’(0x33) Response this status while receive
the first Enquiry command after
card out
Dispensing error ‘4’(0x34) Response this status while
dispensing error
Dispenser
pre-dispense card
‘5’(0x35) Response this status while
pre-dispense card
Dispense command
can not be executed
‘6’(0x36) When stacker is empty of cards or
error occurs on the dispenser, or
dispenser is waiting for card being
taken. Dispenser will not execute
Dispensing command. Response
this status after receive first
Enquiry command.
