Model No. CRT-541
SPECIFICATION
Date 2010/01/10
Ver. 1.0
Card Dispenser
Page
13/16
6.2 DIP Setting Of Unit Address
The following table shows the Dip setting of Unit Address.
Multi-switch
4 3 2 1
Corresponding address
ON ON ON ON ‘00’
ON ON ON OFF ‘01’
ON ON OFF ON ‘02’
ON ON OFF OFF ‘03’
ON OFF ON ON ‘04’
ON OFF ON OFF ‘05’
ON OFF OFF ON ‘06’
ON OFF OFF OFF ‘07’
OFF ON ON ON ‘08’
OFF ON ON OFF ‘09’
OFF ON OFF ON ‘10’
OFF ON OFF OFF ‘11’
OFF OFF ON ON ‘12’
OFF OFF ON OFF ‘13’
OFF OFF OFF ON ‘14’
OFF OFF OFF OFF ‘15’
Note: Address default setting is ‘15’.
