p. 59
master module
output EQ features
equalizer—EQ ON
Equalizer is on. This switch can be used to make A/B comparisons
between flat and eq’d signals.
left, right, mono equalization—EQ TO LEFT, TO RIGHT, TO MONO
These three switches select the signals fed to each of the first three
eq’s on the first three master sub-modules.The fourth
MASTER sub-module
does not include a switch because its source is always
MATRIX 2.
AUX 5 and 6 are fed to the first two eq’s.
MATRIX
1 is fed to the third eq.
left, right and/or mono are fed to the first three eq’s.
