6. Finally pull out the tool
Extract the filter (inverse insertion procedure):
1. Push the top of the extraction tool.
2. Insert the extraction tool in the filter slot of emission wheel. Make sure the extraction tool is
completely inserted against the wall indicated by the red arrow (see picture above)
3. Once in position push a little the toll toward the filter and release in order to grab the filter and
extract it.
