crest Optics X-Light V2 TP - 3.0 X-Light V2 TP Options; 3.1 VCS - Video Confocal Super-resolution

37
3.0 X-Light V2
TP
options
3.1 VCS – Video Confocal Super-resolution
Fig 1.2 CREST X-Light V2
TP
with VCS complete system.
3.1.1 Crest VCS description
Crest VCS is an add-on module for X-Light V2
TP
resolution enhancement.
Specifications
VCS scanner
Glass mask with double square grid hole
pattern
Pattern specifications
 13um diameter, 78um pitch (grid)
13um diameter, 78um pitch (slits)
Spectral transmission
360 nm – 700 nm
Illumination source
Lumencor LEDs Systems, Laser illumination
System
