Observation
EMCCD cameras or sCMOS camera port with
fixed position; camera pixel ≤ 6.5um for higher
sampling
Microscope Compatibility
Inverted fluorescence microscopes with 100%
camera port
Control
USB serial control
Software
Metamorph, Nis-Elements
Power*
15V Vdc 1.5A, 47-63Hz
*If you use external power, specifics are: Vin 110-240 Vac, Vout 15Vdc, 2.5A
Key features:
• Bypass mode for wide-field illumination and acquisition
• Motorized control for VCS pattern focusing and color correction
• Piezo motors system for structured illumination scan
• Two patterns on the same physical glass mask
• Motorized mask positioning from VCS mode to wide-field and confocal mode
• Excitation mount for easy alignment
• LED and Laser excitation mounts for high efficiency coupling
• Adapter for SMA-905 fiber excitation
