Replacement procedure
Use gloves for the entire procedure
Insertion:
1. Put the piezo motors group in the fourth position ( command “D3”, maintanance mode)
2. The glass mask has an arrow on the side. It must be inserted with the arrow pointing toward the light source.
Extraction:
1. Put the piezo motors group in the fourth position ( command “D3”, maintanance mode)
2. Gently push the mask upwards on the outer side. A little lift is necessary to disengage the mask from the
mounting
