1.2 CREST X-Light V2
TP
Confocal Imager
Specifications
Confocal scanner
Nipkow spinning Disk (pinholes) with single
and double hole pattern
Disk scan rate
> 2000 scans per second
Pinhole diameter
60 micron single pattern standard, 40-70
micron double pattern standard, custom pattern
on request
Spectral transmission
360 nm – 700 nm
Z- resolution
0.7 micron (PSF); 60X PlanApo 1.4NA
Illumination source
Lumencor LEDs Systems, Laser illumination
System
Internal excitation changer
On request
Internal dichroic changer
Automated 5 position wheel (up to 25.5x36 mm
filters).
Internal emission changer
Automated 8 positions wheel (25mm diameter,
up to 5mm thick filter).
Operation mode
Automated confocal, wide field, bright field,
super-resolution with VCS module add-on
(option)
Observation
CCD camera/sCMOS camera port with fixed
position; manual focusing by X-Light V2
TP
focusing hex screw system
Microscope Compatibility
Inverted fluorescence microscopes with 100%
camera port. Upright Microscopes
Control
USB serial control
Software
Metamorph, Nis-Elements, MicroManager
Size
11.4 (w)x 14.2 (L) x 9.06 (h) inches
29.00 (w) x 36.00 (L) x 23.00 (h) cm
Sound noise
Background 37db working 45db
Working Temperature
15-35 °C
Storage Temperature
10-70°C
Weight
24.3 lbs /11.0Kg
Power
100-240VAC 2.5A 47-63Hz
graphic symbols:
Not dispersion this product in the environment in accordance to RAEE directive 2003/118CE
Attention
