Crestron 3 Series Supplemental Guide

Relays
Select
Relays
to monitor and control the status of the built-in relays.
I/O Control - Relays Screen
Closed relays are indicated in red while open relays are indicated in black. To toggle a relay
between the open and closed states, press left or right on the Nav Pad to highlight the
desired relay, and then press the center button of the Nav Pad to toggle its state.
Versiports
Select
Versiports
to view activity on the Versiports. When a port is in use, the port
configuration (
Digital In
,
Digital Out
, or
Analog In
) is displayed for that port number. If the
port is not in use,
Not In Use
is displayed.
I/O Control - Versiports Screen
To edit the port configuration, select a port by pressing left or right on the Nav Pad to
highlight the desired port, and then press the center button of the Nav Pad to toggle
between the different configurations.
Com Ports
Select
Com Ports
to display the
I/O Control - Com Ports
menu.
I/O Control - Com Ports Menu
The
I/O Control - Com Ports
menu displays a list of the serial ports on the PRO3. Press up
or down on the Nav Pad to highlight the desired serial port, and then press the center
button of the Nav Pad to display com port’s monitor screen.
I/O Control - Relays
1
2
3
4
5
6
7
8
Relay 1, State = Closed
Use Left/Right to navigate
Use ‘Select’ to toggle relay state
I/O Control - Versiports
1 2 3 4
5 6 7
8
Use Left/Right to navigate
Use ‘Select’ to digital output state
Not
In
Use
Not
In
Use
Not
In
Use
Not
In
Use
Not
In
Use
Not
In
Use
Not
In
Use
Not
In
Use
I/O Control - Com Ports
Com Port 1
Com Port 2
Com Port 3
Com Port 4
Com Port 5
Supplemental Guide – DOC. 7330D PRO3: 3-Series Control System • 13
