message, "Touch Upper Left Corner", appears in the upper left corner. Touch the
corner of the screen to initiate calibration. Another message, "Touch Lower Right
Corner", appears in the lower right corner. Touch the corner of the screen to return to
the Main Menu.
Calibration Menu
Diagnostics Menu
The DIAGNOSTICS button from the Main Menu should only be used under
supervision from a CRESTRON technical support representative during telephone
support. The options available from the Diagnostics Menu, shown below, are
numeric in nature and their interpretation is beyond the scope of this manual.
Diagnostics Menu
Setup Menu
To obtain the Setup Menu, shown below, select and hold the SETUP button from the
Main Menu until the Setup Menu is displayed. Many options for setting parameters
of the touchpanel are available from the Setup Menu and are explained in the
following paragraphs. After setup parameters have been set, select the Return
button, located at the lower right corner of the Setup Menu.
Setup Menu
Operations Guide - DOC. 5725 Series 3200 Touchpanels • 11
