CRESTRON
Series 3200 Touchpanels
Description
Functional Description
The Series 3200 touchpanels are 10.4 inch (26.4 cm) passive matrix touchscreen
control panels for the Cresnet remote control system (herein referred to as the
Cresnet system). There are two Series 3200 configurations available: either lectern-
mount or adjustable tiltcase models. Configuration selection is based on application
requirements. Refer to “Configuration Differences” on page 5 for a more detailed
description of each.
The purpose of a Series 3200 unit is to replace hard-wired panels in either a Cresnet
or an RS-232 based control system. The touchpanel is capable of replacing large,
complicated panels with a series of simpler screens, each specific to the control
problem at hand. Thus, very large numbers of functions can be made available to the
user without the confusion associated with hardware panels of that complexity.
Series 3200's icons, graphics, and text can dramatically increase any user's
comprehension of the control environment. Devices, functions, and control zones are
quickly organized and more easily accessed. The Series 3200 touchpanels offer:
• 256-color display
• pop-up sub panels to reduce memory requirements, providing optimal
speed and performance
• multiple button, slider control, and icon configurations
• up to 999 functions and 96 screens
• imported photographs, drawings, and icons
• support for downloadable fonts - proportional and non-proportional
• foreign language text
• RS-232 interface for stand-alone applications (lectern-mount
configuration only)
• printout of screen designs on standard printer
• Position Lock feature provides durable support of panel at any angle of
inclination between 0 and 70 degrees (tiltcase configuration only).
Operations Guide - DOC. 5725 Series 3200 Touchpanels • 1
