High Powered RF Gateway Crestron CEN-HPRFGW
Configuration
Manager
Configuration Manager is the view where programmers “build” a
Crestron control system by selecting hardware from the Device Library.
• To incorporate the CEN-HPRFGW into the system, drag the
CEN-HPRFGW from the Wireless Receivers | Wireless Receivers
(RF) folder of the Device Library and drop it in the System Views.
Locating the CEN-HPRFGW in the Device Library
• The system tree of the control system displays the device in the
appropriate slot(s) with a default Net ID or IP ID as shown in the
following illustration.
NOTE: A single CEN-HPRFGW should be on either Cresnet or
Ethernet but not both.
C2Net Device, Slots 8 and 9
• Additional CEN-HPRFGW devices are assigned different Net ID
or IP ID numbers as they are added.
16 • High Powered Gateway: CEN-HPRFGW Operations & Installation Guide – DOC. 6587B
