2-Series Integrated Control Processor Crestron CP2/CP2E
bit Motorola ColdFire
processor. The 2-Series operating system is vastly upgraded
from Crestron’s X-generation products, yet compatible with existing Crestron
software and programming. A key feature is the new Crestron Compiler, which
allows any existing Crestron SIMPL™ Windows
control program to be easily
recompiled for the 2-Series. The real-time, preemptive multi-tasking/multi-threaded
operating system offers a file system that supports long file names. The enhanced
SIMPL+™ instruction set is also fully compatible with existing Crestron SIMPL
Windows and SIMPL+ programs.
Specifications
Specifications for the CP2 and CP2E are given in the following table.
CP2/CP2E 2-Series Integrated Control System Specifications
SPECIFICATION DETAILS
CPU 32-Bit Motorola ColdFire
®
Processor
Processor Speed 257 MIPS (Dhrystone 2.1 Benchmark)
Memory 36MB (4MB flash, 32MB DRAM, 256KB NVRAM)*
Ports/Connectors**
NET
COMPUTER
INFRARED – SERIAL OUTPUT
I/O
RELAY OUTPUT
LAN (CP2E only)
COM (A, B, & C)
24VDC
Reset Buttons
HWR
SWR
1 – Cresnet 4-wire interface (Expandable via Cresnet
Poll Accelerator)
1 – DB9F PC interface
8 – Simultaneous one-way IR or serial output
8 – Programmable digital/analog inputs & digital outputs
8 – Normally open, isolated relays (MOV suppression)
1 – RJ45 10/100 BaseT Ethernet port
3 – DB9 bidirectional serial ports (RS-232, -422, -485),
all Cresnet Poll Accelerator ready
1 – Male receptacle for optional external power pack.
Initiates system hardware reset
System restart with or without program
Power Requirements 24 VDC, 1A, 24W (Power supply not included)***
Network Power Fuse Rating Internal self-resetting fuse****
Environmental Temperature &
Humidity
41° to 113°F (5° to 45°C)
10% to 90% RH (non-condensing)
Dimensions & Weight Height: 1.7 in (4.32 cm)
Width: 19.0 in (48.26 cm) – with ears
17.03 in (43.24 cm) – without ears
Depth: 6.64 in (16.87 cm)
Weight: 3.54 lb (1.59 kg)
* For more information on system memory usage, see Memory on page 7.
** For more information on controls, ports, and indicators, see Physical Description on page 3.
*** For information on optional power source, see Optional Power Supply on page 13.
**** Heat-sensitive device—resets within approximately 30 seconds after overload condition is
removed.
2 2-Series Integrated Control Processor: CP2/CP2E Operations Guide - DOC. 5980
