Crestron DIN-8SW8 DIN Rail High-Voltage Switch
DIN Rail High-Voltage Switch:
DIN-8SW8
Introduction
The DIN-8SW8 is an eight channel lighting control module designed to
support switching of non-dimmable lighting and fans. A single model
supports both 120 and 220-240 Volt applications. Each channel handles
incandescent loads up to 10 Amps, fluorescent loads up to 5 Amps, and
also 1/2 HP motors.*
Features and Functions
• Eight channels of power switching
• Supports 120 to 240 Volt 50/60 Hz
• Override input
• Cresnet
®
communications
• Setup via front panel or software
• Programmable functionality via DIN-AP2
• 9M wide DIN rail mounting
* May not be compatible with some high inrush current loads.
Operations & Installation Guide – DOC. 6666B DIN Rail High-Voltage Switch: DIN-8SW8 • 1
