DIN Rail High-Voltage Switch Crestron DIN-8SW8
Specifications
Specifications for the DIN-8SW8 are listed in the following table.
DIN-8SW8 Specifications
SPECIFICATION DETAILS
Load Ratings
Switch Channels 8
Maximum Per Channel 10 Amps incandescent,
5 Amps fluorescent,
0.5 HP @ 120 to 240 Volts AC,
50/60 Hz;
5 Amps @ 30 Volts DC;
16 Amps Resistive
Module Total 80 Amps incandescent,
40 Amps fluorescent, @ 120-240
Volts AC, 50/60 Hz
Load Types
1
Incandescent,
magnetic low-voltage,
electronic low-voltage,
neon/cold cathode,
fluorescent, motors
Power Requirements
Cresnet Power Usage 5.4 Watts
(0.23 Amps @ 24 Volts DC)
Default Net ID 89
Minimum 2-Series
Control System Update
File
2, 3
Version 4.000.0226 or later
Environmental
Temperature 0º to 40º C (32º to 104º F)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 18 BTU/Hr
(Continued on following page)
4 • DIN Rail High-Voltage Switch: DIN-8SW8 Operations & Installation Guide – DOC. 6666B
