Programming Guide – DOC. 7365A DIN Rail 2 Channel DALI Interface: DIN-DALI-2
•
13
Examples for Sending Ballast to Off
ADDRESS COMMAND
Short address 00
SENDDALIPKT 1 0100
Short address 06
SENDDALIPKT 1 0D00
Short address 63
SENDDALIPKT 1 7F00
Group address 15
SENDDALIPKT 1 9F00
Examples for Querying Status
ADDRESS COMMAND
Short address 00
SENDDALIPKT 1 0190
Short address 06
SENDDALIPKT 1 0D90
Short address 63
SENDDALIPKT 1 7F90
• Syntax: SENDDALIPKT [LOOP] [ADDR][DATA]
NOTE: There is no space between the ADDR and DATA bytes.
Refer to the following tables when generating raw DALI packets.
Byte Equivalents for Short and Group Addresses
SHORT
ADDRESS
ADDR
BYTE
SHORT
ADDRESS
ADDR
BYTE
SHORT
ADDRESS
ADDR
BYTE
SHORT
ADDRESS
ADDR
BYTE
GROUP
ADDRESS
ADDR
BYTE
0 01 16 21 32 41 48 61 0 81
1 03 17 23 33 43 49 63 1 83
2 05 18 25 34 45 50 65 2 85
3 07 19 27 35 47 51 67 3 87
4 09 20 29 36 49 52 69 4 89
5 0B 21 2B 37 4B 53 6B 5 8B
6 0D 22 2D 38 4D 54 6D 6 8D
7 0F 23 2F 39 4F 55 6F 7 8F
8 11 24 31 40 51 56 71 8 91
9 13 25 33 41 53 57 73 9 93
10 15 26 35 42 55 58 75 10 95
11 17 27 37 43 57 59 77 11 97
12 19 28 39 44 59 60 79 12 99
13 1B 29 3B 45 5B 61 7B 13 9B
14 1D 30 3D 46 5D 62 7D 14 9D
15 1F 31 3F 47 5F 63 7F 15 9F
