DigitalMedia 8G Fiber Receiver Crestron DM-RMC-SCALER-S/S2
22  DigitalMedia 8G Fiber Receiver: DM-RMC-SCALER-S/S2 Operations & Installation Guide – DOC. 7324B
The system tree of the control system displays the DM receiver in the
appropriate slot with a default IP ID as shown in the following illustrations.
In the first example, the DM-RMC-SCALER-S is used with the DMCO-40
output card in a DM-MD8X8 switcher. In the second example, the
DM-RMC-SCALER-S is used with the C2ENET-2 card in an Ethernet slot
on the control system.
C2ENET-2 Device, Slot 8 (Using Output Card in a DM Switcher)
C2ENET-2 Device, Slot 8 (Using Ethernet Slot on Control System)
2. If additional DM receivers are to be added, repeat step 1 for each device.
Each DM receiver is assigned a different IP ID.
3. If necessary, double-click a device to open the “Device Settings” window
and change the IP ID as shown in the following illustration.
“Device Settings: Crestron DM-RMC-SCALER-S” Window
