Crestron TPS-6 Isys™ 5.7” Tilt Touchpanel
TPS-6 Specifications (Continued)
SPECIFICATION DETAILS
Default Net ID 03
Minimum 2-Series Control
System Update File
3, 4
Version 3.155.1240 or later
Environmental
Temperature
32º to 112ºF (0º to 45ºC)
50º to 104ºF (10º to 40ºC) while charging
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 30 BTU/Hr
Enclosure
Construction
Plastic, 45° to 90° adjustable friction clutch
tilt mechanism, low-profile base, integral
cable assembly, swivel mount kit available
separately
Front Bezels
Button and no-button bezels included; button
bezel includes white translucent illuminated
Up/Down and Thumbpad buttons and eight
hardkey buttons with illuminated dividers and
default backlit
5
text engraving, optional
custom backlit
5
text engraving sold
separately
Dimensions
Height 6.21 in (158 mm) maximum
Width 8.08 in (206 mm)
Depth
7.02 in (179 mm), 6.53 in (166 mm) without
grommet
Weight 2.9 lbs (1.3 kg)
Available Models
TPS-6 Isys 5.7” Tilt Touchpanel, High Gloss Black
TPS-6-B-T Isys 5.7” Tilt Touchpanel, Matte Black
TPs-6-W-S Isys 5.7” Tilt Touchpanel, High Gloss White
Included Accessories
Power Pack 24 Volt Power Pack
TPS-6X-FP
Button Bezel with Default Engraving
(specify color)
TPS-6X-FP-NB No Button Bezel (specify color)
TPS-6X-IMCW Interface Module
Available Accessories
SMK-6X Swivel Mount Kit
TPS-6X-FP
Button Bezel w/Custom Engraving
(specify color)
1. May be powered by 24 Volts DC or Cresnet network power but not both.
2. Item is included with the TPS-6; refer to individual product specifications for additional information.
3. The latest software versions can be obtained from the Crestron
®
website. Refer to the NOTE
following these footnotes.
4. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
5. Text engraving on the TPS-6-W-S white model is not backlit.
Operations Guide – DOC. 6945A Isys™ 5.7” Tilt Touchpanel: TPS-6 • 5
