Isys™ 5.7” Tilt Touchpanel Crestron TPS-6
Specifications
Specifications for the TPS-6 are listed in the following table.
TPS-6 Specifications
SPECIFICATION DETAILS
Touchscreen Display
Display Type TFT Active matrix color LCD
Size 5.7 inch (145 mm) diagonal
Aspect Ratio 4:3 VGA
Resolution 640 x 480 pixels
Brightness 350 nits
Contrast 400:1
Color Depth 18-bit, 256 k colors
Illumination Backlit fluorescent
Viewing Angle ±80º horizontal, +80º/-70º vertical
Touchscreen Resistive membrane
Processor
CPU 32-bit Freescale ColdFire
®
Microprocessor
Memory
SDRAM 32 MB
Flash 32 MB
Maximum Project Size 28 MB
Graphic Engine
Isys engine; 16-bit non-palette graphics;
65,536 colors; Synapse image rendering
algorithm; multi-mode objects, dynamic
graphics, PNG translucency, full-motion (60
fps) animation, color key video windowing
Ethernet
10BASE-T/100BASE-TX, auto-switching,
auto-negotiating, auto-discovery, full/half
duplex, TCP/IP, UDP/IP, CIP, DHCP, IEEE
802.3U compliant
Video
Signal Types Composite
Formats NTSC 480i or PAL 576i
Color Depth 18-bit, 262,144 colors
Windowing
Single window, deinterlaced and scalable up
to full screen
Audio Internal transducer for key click sound
Power Requirements
1
24 VDC Power Consumption
0.75 Amps @ 24 Volts DC including
interface module
Power connection is via TPS-6X-IMCW
interface module
2
Cresnet Power Usage
16 Watts (0.67 Amps @ 24 Volts DC)
including interface module
Power connection is via TPS-6X-IMCW
interface module
2
(Continued on following page)
