Com Port 1 Monitor Screen
The monitor displays incoming and outgoing data. Transmitted data is displayed in red and
received data is displayed in green.
Use the Nav Pad and the center button to perform the following actions:
• Press the center button of the Nav Pad to record transmitted and received data.
Press the center button again to pause.
• Press up or down on the Nav Pad to scroll through transmitted and received data.
• Press left on the Nav Pad to clear data from the screen.
• Press right on the Nav Pad to configure the com port. The
Com Port Setup
menu
is displayed.
Com Port 1 Setup Menu
1. Press up or down on the Nav Pad to highlight the parameter to be adjusted,
and then press the center button on the Nav Pad to display the available
settings.
2. Press up or down on the Nav Pad to highlight the desired setting, and then
press the center button of the Nav Pad to select it.
3. Repeat steps 1 and 2 for every parameter to be adjusted.
4. Press
BACK
to return to the previous screen.
Com Port 1 Monitor
Select = Record/Pause
Up/Down = Scroll Data
Left = Clear Data
Right = Setup Port
Tx =
Rx = Recording
Com Port 1 Setup
Baud Rate
Parity: None
Data Bits: Unknown
Stop Bits: Unknown
HW Handshake: None
14 • PRO3: 3-Series Control System Supplemental Guide – DOC. 7330D
