PSPHD Overall Dimensions
17.08 in
(434 mm)
17.28 in
(439 mm)
5.20 in
(133 mm)
5.74 in
(146 mm)
14.75 in
(375 mm)
13.89 in
(353 mm)
1
2
3 8 11 16
4 5 6 7 10
9
12 13 14 15 17
18
19
20 21 22
23
24 25 27
29
30
31
28
26
18 • PROCISE™ Surround Sound Processor: PSPHD Operations Guide – DOC. 6837B
