TPS-4L 3.6-Inch Wall Mount Touchpanel
• Use the Address Book in the Crestron Toolbox to create an entry for the
TPS-4L with the TPS-4L’s TCP/IP communication parameters.
• Display the “System Info” window (click the
icon) and select the
TPS-4L entry.
Programs, Projects and Firmware
Program, project or firmware files may be distributed from programmers to installers
or from Crestron to dealers. Firmware upgrades are available from the Crestron
website as new features are developed after product releases. One has the option to
upload programs and projects via the programming software or to upload and
upgrade via the Crestron Toolbox. For details on uploading and upgrading, refer to
the SIMPL Windows help file, VisionTools Pro-e help file or the Crestron Toolbox
help file.
SIMPL Windows
If a SIMPL Windows program is provided, it can be uploaded to the control system
using SIMPL Windows or Crestron Toolbox.
VisionTools Pro-e
Upload the VisionTools Pro-e file to the touchpanel using VisionTools Pro-e or
Crestron Toolbox.
Firmware
Check the Crestron website to find the latest firmware. (New users may be required
to register to obtain access to certain areas of the site, including the FTP site.)
Upgrade TPS-4L firmware via Crestron Toolbox.
• Establish communication with the TPS-4L and display the “System Info”
window.
• Select Functions | Firmware… to upgrade the TPS-4L firmware.
Program Checks
Actions that can be performed on the TPS-4L vary depending on whether it is
connected via Cresnet or Ethernet.
Cresnet Connections
For Cresnet connections, using Crestron Toolbox, display the network device tree
(Tools | Network Device Tree) to show all network devices connected to the control
system. Right-click on the TPS-4L to display actions that can be performed on the
TPS-4L.
Ethernet Connections
For Ethernet connections, display the “System Info window (click the
icon) and
select the Functions menu to display actions that can be performed on the TPS-4L.
Be sure to use the Crestron Toolbox to create the TPS-4L IP table.
• Select Functions | IP Table Setup.
• Add, modify or delete entries in the IP table. The TPS-4L can have only one
IP table entry.
• A defined IP table can be saved to a file or sent to the device.
Edit the control system’s IP table to include an entry for the TPS-4L. The entry
should list the TPS-4L’s IP ID (specified on the TPS-4L’s IP table) and the internal
gateway IP address 127.0.0.1.
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel:
TPS-4L • 25
