Crestron Isys
®
TPS-4L 3.6-Inch Wall Mount Touchpanel
TPS-4L Specifications (Continued)
SPECIFICATION DETAILS
Processor
CPU 32-bit Freescale ColdFire® Microprocessor
Memory
DRAM 16 MB
Flash 8 MB
Maximum Project Size 7 MB
Graphic engine
Isys engine; 16-bit non-palette graphics; 65,536
colors; synapse image rendering algorithm,
multi-mode objects, dynamic graphics, PNG
translucency, full-motion (60 fps) animation
Ethernet
10BaseT/100BaseTX, auto-switching,
auto-negotiating, full/half duplex, TCP/IP, UDP/IP,
CIP, DHCP, IEEE 802.3U compliant
Audio
Hardware Feature
Built-in amplified speaker (rear), internal volume
control
Audio Feedback
(WAV)
8-bit PCM, mono, 8 kHz sampling rate
Amplification 1 Watt for built-in speaker
Power
Cresnet Power Usage 5 Watts (0.21 Amp @ 24 Volts DC)
Default Net ID 03
Firmware
tps-4l_c2n-ft-tps-4_qm-ftcc-tps_tps-4_2.007.0163
or later
Minimum 2-Series Control
System Update File
1, 2, 3
Version 3.137.CUZ or later
Environmental
Temperature 32º to 104ºF (0º to 40ºC)
Humidity 10% to 90% RH (non-condensing)
Enclosure
Construction
Injection-molded plastic, flush-mountable using
clips provided (additional mounting kits available)
Faceplate Injection-molded plastic
Dimensions
Height 4.54 in (11.52 cm)
Width 6.19 in (15.72 cm)
Depth 2.13 in (5.40 cm)
Weight 15 oz (0.43 kg)
1. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following
these footnotes.
2. Crestron 2-Series control systems include the AV2 and PRO2. Consult the latest Crestron Product
Catalog for a complete list of 2-Series control systems.
3. When loading VisionTools Pro-e files or firmware through the RS-232 port of the control system, be
sure that the baud rate is at 38400 (Cresnet speed) or lower. Otherwise, Toolbox may post the
“Transfer Failed” message.
Operations & Installation Guide – DOC. 6449A 3.6-Inch Wall Mount Touchpanel:
TPS-4L • 3
