Clip SGD
Software overview
1 Tab menus
File
•฀฀Load:฀Open฀the฀installed฀settings.฀(*cfg)
•฀฀Save:฀Save฀the฀current฀settings.฀(*cfg)
•฀฀Exit:฀Close฀the฀program.
Tools
•฀฀Calibration:฀Perform฀the฀ZERO/SPAN฀calibration.
•฀฀Log฀Read:฀Retrieve฀the฀log฀events.
•฀฀Log฀Erase:฀Erase฀log฀events.
•฀฀Self฀Test:฀Test฀if฀LED,฀LCD,฀Buzzer,฀vibration,฀battery฀and฀temperature฀work฀properly.
•฀฀Firmware฀Upgrade:฀For฀the฀latest฀rmware฀version,฀go฀to฀www.crowcon.com฀or฀contact฀
your฀local฀service฀agent.฀After฀a฀rmware฀update,฀the฀detector฀MUST฀be฀recalibrated.
•฀฀Factory฀Default:฀Remove฀all฀data฀and฀restore฀the฀initial฀factory฀settings.฀After฀factory฀
settings฀are฀restored,฀the฀detector฀must฀be฀recalibrated.
Help
•฀฀About:฀Display฀a฀brief฀company฀prole.
2 Tool Interface
•฀฀READ:฀Retrieve฀settings
•฀฀WRITE:฀Update฀and฀adjust฀settings.
•฀฀LOG:฀Display฀the฀saved฀log฀events.
•฀฀CALIBRATION:฀Perform฀the฀ZERO฀and฀SPAN฀calibration
•฀฀FIRMWARE฀UPGRADE:฀Upgrade฀rmware.
3 IR Link Interface
•฀฀In฀order฀to฀interact฀with฀the฀Clip฀SGD฀using฀the฀IR฀Link,฀click฀“OPEN”.฀When฀the฀Clip฀
SGD฀settings฀have฀been฀successfully฀retrieved฀users฀will฀see฀“Read฀Complete”.
4 Clip SGD Interface
•฀฀Serial฀Number:฀Display฀a฀preset฀serial฀number.
•฀฀Firmware฀Version:฀Display฀a฀rmware฀version.
•฀฀User฀ID/Message:฀Users฀can฀program฀a฀desired฀message/ID.
•฀฀Display:฀Users฀can฀choose฀to฀display฀either฀the฀real฀time฀“Sensor฀Reading”฀or฀“Sensor฀
Life฀Remaining”
•฀฀Stealth฀(Option):฀Users฀can฀turn฀off฀the฀buzzer,฀LED,฀and฀vibration.
