Clip SGD
1. Diagram and LCD
1.฀ IR฀Port
2.฀ LCD฀display
3.฀ Alarm฀LED
4.฀ Buzzer
5.฀ Button
6.฀ Gas฀sensor
7.฀ Gas฀Type
LCD display symbols
ALARM
Alarm฀condition
M
Months฀remaining฀
1
Low฀alarm฀
D
Days฀remaining฀
2
High฀alarm฀
T
Time฀remaining฀(hours)
v
Test฀success
MAX
Maximum฀peak฀value
x
Test฀failure
MN
I
Minimum฀peak฀value
Fresh฀air฀calibration
LEL
PPM
VOL
%
%
Measurement฀Unit
Standard฀gas฀calibration
Low฀battery฀life฀
(Less฀than฀30฀days)
1
2
4
5
6
7
3
3
3
MAX
LEL
PPM
VOL
%
%
MN
I
ALARM
1
V
M
D
T
X
2
