Crowcon Clip SGD - Page 9

9
Clip SGD
The฀table฀below฀shows฀the฀‘alarms’฀and฀‘alerts’฀that฀may฀be฀shown฀on฀the฀display฀during฀
operation.
฀
AlarmAlarm฀StandardShown฀on฀LCD฀
Display
Alarm฀and฀Vibration฀Display
Low฀AlarmExceeds฀1st฀
Alarm฀set฀point
1
฀icon฀&฀
concentration
Buzzer,฀LED
Vibration
High฀AlarmExceeds฀2nd฀
Alarm฀set฀point
2
฀icon฀&฀
concentration
Buzzer,฀LED
Vibration
Remaining฀lifeBelow฀30฀days
฀icon฀
Lifetime฀
expiration฀
Past฀24฀months
Service฀life฀is฀over฀
(Replace฀with฀a฀new฀Clip฀SGD)
Test฀failureFailure฀of฀
sensor฀test฀/฀
calibration
Display฀
฀
X
฀
฀icon฀with฀
beeping
Battery฀testLow฀power
Bump฀testBump฀test฀
period
VX
Press฀the฀push฀button฀to฀turn฀off฀
the฀alarm
CalibrationCalibration฀
period
Press฀the฀push฀button฀to฀turn฀off฀
the฀alarm
⚠ CAUTION
Default฀alarm฀set฀points฀are฀based฀on฀common฀international฀standards.฀It฀is฀user฀
responsibility฀to฀ensure฀the฀congured฀alarm฀set฀points฀are฀in฀accordance฀with฀local฀
regulations฀and฀site฀procedures.฀
