Crown CT 475 DriveCore - Specifications

page 51
CT Power Amplifiers
Operation Manual
16 Specifications
Performance CT475 CT4150 CT875 CT8150
Channels 4 4 8 8
Sensitivity 1.4V 1.4V 1.4V 1.4V
Rated Power Output
75W per channel
into 8/4 ohms
125W per channel
into 8/4 ohms
75W per channel
into 8/4 ohms
125W per channel
into 8/4 ohms
Signal to Noise Ratio (below rated power 20Hz to 20kHz, A-Weighted) 110 dB 110 dB 110 dB 110 dB
Total Harmonic Distortion (THD) (full rated power, 1kHz) < 0.05% < 0.05% < 0.05% < 0.05%
Intermodulation Distortion (from 0dB down to -30dB) < 0.05% < 0.05% < 0.05% < 0.05%
Frequency Response (at 1W into 4/8 ohms) ± 0.5 dB ± 0.5 dB ± 0.5 dB ± 0.5 dB
Common Mode Rejection (20Hz to 1kHz) > 70 dB > 70 dB > 70 dB > 70 dB
Load Ranges 2-8 Ohms 2-8 Ohms 2-8 Ohms 2-8 Ohms
General CT475 CT4150 CT875 CT8150
Dimension (H x W x D) 1.75” x 19” x 15.19” 1.75” x 19” x 15.19” 1.75” x 19” x 15.19” 1.75” x 19” x 15.19”
Net Weight 10 lbs 10 lbs 10 lbs 10 lbs
Net Shipping Weight 15 lbs 15 lbs 15 lbs 15 lbs
*26dBgain
**Amplifier is stable for 20hm loads
* * * *
