CRT ALPHA - 1. KNOW ABOUT THIS RADIO

Down
UP
Microphone cable
Mic
PTT
Connector
1. KNOW ABOUT THIS RADIO
1 Mode/Keypad lock
2 Squelch control, SQ, ASQ switch key
3 Microphone Jack
4 Channel up selector
5 Channel down selector
6 Emergency channel
7 Power On/Off Volume control
8 External speaker Jack
9 Antenna Jack
ANT
POWER
EXT.SP
8
9
- 4 -
EMG
MENU
VOL
CH
SQ/AQ
AM/FM
1
2
6
7
3
4
5
