Crunch GTS1100 - Specifications

7
Contents
General Installation Notes
Installation of the amplifier, Electrical Connection
GTS1100 Monoblock
Amplifier - Features
Amplifier - Applications
Trouble Shooting
Page
8
9
10
11
* All specifications subject to change without notice
Channels
Output Power Ratings at 14.4 Volts
WWatts at 4 Ohms - RMS / MAX.
WWatts at 2 Ohms - RMS / MAX.
WWatts at 1 Ohms - RMS / MAX.
Damping factor
Signal to noise ratio
THD & N
Input Gain Control
Crossover Channel 1 & 2
Variable Lowpass Crossover 12 dB
Variable Subsonic Filter
BassBoost Control at 45Hz
RCA Line Outputs
Bass Remote Control
Heatsink size in mm
Width x Height
Lenght
GTS1100
1
275 / 550
400 / 800
500 / 1000
> 200
>95dB
< 0.5%
0.2 - 5 Volt
40Hz - 150Hz
15Hz - 55Hz
0dB - 12dB
Fullrange
Yes
251 x 55
400
Specifications
