Programming Manual 62
Field Description
index
1
to index
84
This field indicates the channel number from 1 to 84 channels
freq This field indicates the frequency corresponding to the index
number
ID This field shows the latest station ID of a beacon corresponding to
the frequency
ch This field is an internal status flag
snr This field indicates the signal to noise ration in dB that was last
measured for that beacon
ss This field indicates the signal strength last measured for that beacon
in dBµV
An example of this message response follows:
$PCSI,ACK,3
$PCSI,01,2835,000,0E,03,0007,02,2840,000,0E,02,0008,03,2845,000,0E,03,0008
$PCSI,04,2850,000,0E,02,0008,05,2855,000,0E,03,0009,06,2860,000,0E,05,0014
$PCSI,07,2865,000,0E,02,0008,08,2870,060,0F,17,0023,09,2875,000,0E,01,0011
$PCSI,10,2880,000,0E,02,0012,11,2885,000,0E,02,0009,12,2890,000,0E,02,0009
$PCSI,13,2895,000,0E,01,0008,14,2900,000,0E,02,0012,15,2905,000,0E,03,0013
$PCSI,16,2910,000,0E,02,0017,17,2915,000,0E,02,0012,18,2920,000,0E,03,0014
$PCSI,19,2925,000,0E,-100,0012,20,2930,000,0E,-100,0018,21,2935,000,0E,-100,0009
$PCSI,22,2940,000,0E,-100,0014,23,2945,000,0E,-100,0011,24,2950,000,0E,-100,0011
$PCSI,25,2955,000,0E,-100,0008,26,2960,000,0E,-100,0009,27,2965,000,0E,-100,0011
$PCSI,28,2970,000,0E,-100,0012,29,2975,000,0E,-100,0012,30,2980,429,0E,-100,0009
$PCSI,31,2985,000,0E,-100,0013,32,2990,000,0F,06,0044,33,2995,000,0F,00,0013
$PCSI,34,3000,000,0F,03,0013,35,3005,733,0E,-100,0011,36,3010,000,0E,-100,0009
$PCSI,37,3015,000,0E,-100,0009,38,3020,000,0E,-100,0015,39,3025,000,0E,-100,0011
$PCSI,40,3030,000,0E,-100,0013,41,3035,000,0E,-100,0009,42,3040,282,0E,-100,0011
$PCSI,43,3045,000,0E,-100,0013,44,3050,000,0F,05,0023,45,3055,000,0E,-100,0012
$PCSI,46,3060,000,0E,-100,0012,47,3065,000,0E,-100,0013,48,3070,000,0E,-100,0008
$PCSI,49,3075,000,0E,-100,0012,50,3080,000,0E,-100,0017,51,3085,000,0E,-100,0013
$PCSI,52,3090,000,0E,-100,0009,53,3095,000,0E,-100,0009,54,3100,000,0E,-100,0017
$PCSI,55,3105,000,0E,-100,0014,56,3110,023,0E,-100,0017,57,3115,000,0E,-100,0011
$PCSI,58,3120,620,0E,-100,0012,59,3125,000,0E,-100,0012,60,3130,062,0E,-100,0022
$PCSI,61,3135,000,02,-100,0013,62,3140,345,0A,-100,0012,63,3145,000,02,-100,0011
$PCSI,64,3150,000,02,-100,0011,65,3155,000,0A,-100,0011,66,3160,000,0A,-100,0016
$PCSI,67,3165,000,0A,-100,0011,68,3170,000,0A,-100,0013,69,3175,000,0A,-100,0012
$PCSI,70,3180,000,0A,-100,0011,71,3185,000,0A,-100,0013,72,3190,000,0A,-100,0013
$PCSI,73,3195,000,0A,-100,0013,74,3200,000,0B,05,0032,75,3205,000,0B,00,0024
$PCSI,76,3210,000,02,-100,0017,77,3215,000,02,-100,0014,78,3220,000,02,-100,0014
$PCSI,79,3225,000,02,-100,0011,80,3230,000,0A,-100,0019,81,3235,684,0A,-100,0011
