COBRA HD | IFUCOBRAHDEN00
INSTRUCTIONS FOR USE
This document is the property of
CSO Costruzione Strumenti Oftalmici srl.
Any reproduction, even partial, it is prohibited.
31/48
Fig 14 - How to place the device
Fig 15 - Protection carters placement
Install the chin rest. Under the support plane, there are two
screws to block the chin rest support to the support plane.
Carry out the electrical connection between the several
components.
Fig 16 - Chin rest placement
