4 DEVICE USE
4.1 HOW TO INSTALL THE DEVICE
CAUTION
Danger of device fall. The electric table must be installed on a
horizontal and stable surface.
1
Place the electric table in the room. The electric table must be
lifted by two people.
2
If present, block the table wheels. Lower the lever of the
brake.
3
Place the power supply under the support plane. Screw the
screws in the four holes.
Fig 12 - Table placement
Fig 13 - Power supply placement
4
Place the device on the support surface on the cogged guides.
5
Block the two protection carters to the cogged wheels on the
support plane.
