4.5 HOW TO ADJUST THE CHIN CUP
1
Inform the patient to take a seat.
2
Move the chin cup left or right. The chosen position will
identify the position of the eye to be tested.
Fig 25 - Adjusting the chin cup
Fig 26 – Chin cup orientation for left eye Fig 27 – Chin cup orientation for right eye
