4.6 HOW TO CAPTURE THE IMAGE
1
Turn the joystick and align the device with the patient's eye.
2
Move towards the eye with the tool. Keep centred the
reflection of the corneal vertex in both the images.
3
Perform some micro movements with the joystick for the best
image alignment.
Fig 31 - Placement of the device Fig 32 - Distance from the patient
4
Press the joystick button to capture the image. The image will
be saved in the gallery.
5
Double click on the captured image to process and visualize on
the computer screen.
Fig 33 - Image acquisition
Refer to the application software instructions for the
managing in the database.
