CSS CANedge2 - Mechanical; Connectivity

CANedge2 Docs, Release FW 01.04.02
0.2.6 Mechanical
• Status indicated using external LEDs
• Robust aluminum enclosure
• Dimensions: 50.2 x 83.4 x 24.5 mm (L x W x H)
12
• Weight: 100g
• Operating temperature: -25 degC to +70 degC
0.2.7 Connectivity
• Physical
– SMA connector for external antenna
13
– The included dipole antenna has a max gain of 2dBi
• WiFi
– Single-band 2.4 GHz
– Supports IEEE 802.11 b/g/n
– Supports “open” and WPA/WPA2 security settings
– Configurable prioritized list of 1-5 WiFi access points
– WiFi module certified in USA, Canada, Europe, Japan, Korea, China, India, Taiwan
• File transfer
– HTTP/HTTPS file transfer
– S3 transfer protocol
1415
– Device identification using globally unique device ID
– Automatic push of log files to remote or local server
– Automatic time synchronization
• Security
– Secure file transfer using TLS 1.2
– Credentials stored on the device can be encrypted
• Over-The-Air (OTA)
– OTA firmware updates (no need for proprietary software)
– OTA configuration updates (no need for proprietary software)
• WiFi heartbeat
– Lets the device periodically upload a small device status file
12
Without external antenna
13
See the installation section for details on e.g. exchanging the antenna
14
Open S3 API allows automated management of server objects
15
Can be used with Amazon Web Services S3, Google Cloud, Microsoft Azure (via gateway) and several self-hosted
open source solutions
