LIN VBAT
The LIN-bus positive reference. Supports systems operating from 4V to 24V.
• LIN1 VBAT: Pin is shared with device supply and shares the supply input protection circuit
• LIN2 VBAT: Tolerates voltage spikes up to 48V. Spikes above this can damage the interface
LIN Data
LIN-bus single-wire data line referenced to LIN VBAT.
0.3.2.2 Basic wiring example
Below example illustrates how the CANedge CAN-bus 1 (channel 1) can be connected.
o--o--------------------o------------ ... ---o-----------o CAN 1 H (pin 7)
| | | | |
+++ | | | +++
|R| | | | |R|
+++ | | | +++
| | | | |
o-----------o--------------------o--- ... ------------o--o CAN 1 L (pin 2)
|CANedge | | Node 1 | | Node N |
+--+--------+--+ +--+--------+--+ +--+--------+--+
| CANH CANL| | CANH CANL| | CANH CANL|
| | | | | |
| Supply GND | | Supply GND | | Supply GND |
+--+--------+--+ +--+--------+--+ ... +--+--------+--+
| | | | | |
o--------------------o------------ ... ---o-----------o SUPPLY (pin 9)
| | |
o--------------------o--- ... ------------o--o GND (pin 3)
0.3.3 Enclosure
The CANedge uses a robust aluminium enclosure - PDF drawings and 3D STEP files can be found in
the online documentation.
0.3.4 SD card
The CANedge uses an extractable SD-card to store device configuration and log files.
Warning: Never extract the SD-card while the device is on. Remove power first and wait a few
seconds for the device to turn off.
0.3.4.1 File organization
The files stored on the SD-card are organized as illustrated by below example:
/
config-XX.XX.json
schema-XX.XX.json
device.json
(continues on next page)
