CANedge2 Docs, Release FW 01.04.02
WFI
The WiFi LED is on when the device is connected to a WiFi access point.
Note: The device only connects to WiFi when a transfer is pending and is otherwise disconnected
(LED off)
0.3.6 Label
A unique label is attached to the back of each device. Examples of the labels are illustrated below.
Note: The data matrix can be scanned to simplify installation of a new device
The label holds the following information:
• Device type: CANedge2
• Production data in format YYYYWW (WW = week number): 201930
• Hardware version: 00.00
• Unique device ID: EA9B650D
• Data matrix (ECC200) containing production date, device ID and the WiFi MAC address: 201930;
EA9B650D;F8F005E40ED6
• FCC ID of internal WiFi controller: 2ADHKATWINC1500U
0.3. Hardware 13
