ID filters properties.id
Filters are checked sequentially, execution stops with the first matching filter element. Max 128 11-bit
filters and 64 29-bit filters.
type: array minItems: 1 maxItems: 192
Name properties.id.items.properties.name
Optional filter name.
type: string maxLength: 16
State properties.id.items.properties.state
Disabled filters are ignored.
type: integer default: 1 options: Disable: [0] Enable: [1]
Type properties.id.items.properties.type
Action on match, accept or reject message.
type: integer default: 0 options: Acceptance: [0] Rejection: [1]
ID format properties.id.items.properties.id_format
Filter ID format. Filters apply to messages with matching ID format.
type: integer default: 0 options: Standard (11-bit): [0] Extended (29-bit): [1]
Filter method properties.id.items.properties.method
The filter ID matching mechanism.
type: integer default: 0 options: Range: [0] Mask: [1]
From (range) / ID (mask) (HEX) properties.id.items.properties.f1
If filter method is Range, this field defines the start of range. If filter method is Mask, this field defines
the filter ID.
type: string maxLength: 8 default: 0
