CANedge2 Docs, Release FW 01.04.02
0.4.5.6 Control
This page documents the control configuration
Configuration file fields
This section is autogenerated from the Rule Schema file.
Control ‘‘ ‘‘
Control signal
Control reception (rx) state properties.control_rx_state
Control CAN-bus reception state (including logging)
type: integer default: 0 options: Disable: [0] Enable: [1]
Control transmission (tx) state properties.control_tx_state
Control CAN-bus transmission state (including logging)
type: integer default: 0 options: Disable: [0] Enable: [1]
Start signal properties.start
$ref: #/definitions/control_signal
Stop signal properties.stop
$ref: #/definitions/control_signal
Control signal object properties.start, properties.stop
ID Format properties.id_format
ID format of the control message.
type:
integer
de-
fault:
1
oneOf: [{'type': 'integer', 'title': 'Standard (11-bit)', 'enum':
[0]}, {'type': 'integer', 'title': 'Extended (29-bit)', 'enum':
[1]}]
Message ID (hex) properties.id
ID of the control message in hex. Example: 00435354.
default: 00435354 type: string
