CTEK MXS 5.0 Troubleshooting Guide

Trouble Shooting Guide 9
The analysis phase is testing if the battery can retain the charger given.
Explanation 1: Large loads are connected to the battery and are draining the
voltage.
Test: Disconnect the battery and try charging again.
Explanation 2: The battery cannot retain the charge given.
Test: The battery needs replacing.
• The error LED is lit
Explanation 1: Reverse polarity.
Test: Make sure that the + cable/clamp is connected to the + terminal and the
– cable/clamp is connected to the – terminal.
Explanation 2: The clamps are short circuited.
Explanation 3: For chargers of the older type the error mode is flashing when
only the plug is connected.

CTEK MXS 5.0 Specifications

General

Input voltage	220-240 V
Input frequency	50/60 Hz
Battery voltage	2 V
Cable color	Black
Operating temperature (T-T)	-20 - 50 °C
Number of batteries supported	-
Product color	Black, Silver

Weight and Dimensions

Depth	168 mm
Width	65 mm
Height	38 mm
Weight	600 g
