CTR Logika - Technical Characteristics

4/16
Logika - use and maintenance guide page
The technical specications in the chart below are given for the models according to the type
of refrigerant used.
Description
Unit
Measure
R12
Values
R134a
Values
Max. absorbed power W 800 800
Net weight Kg 81 81
Overall dimensions (HxLxP) Mm
1040x540x600 1040x540x600
Fully charged weight kg 100 100
Vacuum ow rate lt/min 66 66
Max. vacuum mbar 0.01 0.01
Filter absorption capacity (rate) gr H
2
O 80 80
System recovery rate gr/min 400 400
Refrigerant cylinder capacity kg 10 10
Supply voltage V 220/240 220/240
Supply frequency Hz 50 50
Max. absorbed current A 5,0 5,0
Coupling diameter on vehicle (Low Pressure LP) mm 11 13
Coupling diameter on vehicle (High pressure HP) mm 11 16
Max. operating temperature °C 50 50
Min. operating temperature °C 5 5
Max. pressure pneumatic circuit bar 18 18
2. Technical characteristics
For supply voltage, always use the value indicated on the machine plate.
The acoustic pressure value for the machine is below 70dBA and therefore no special
precautions need to be taken by the operator even in the case of continuous use
(standard ISO 3746). However, it is the responsibility of the employer to evaluate
noise level exposure of workers in compliance with the directives concerning work
hygiene and safety.
