CTX MyPOOL Series User Manual

16
ENGLISH
Common features
 The products are manufactured according regulation
 Plastic housing in PP
 Level control setting included (supplied without probe)
 Standard power supply (fluctuations not to exceed ±10%): 230 V a.c. 50 Hz single phase.
 del ±10%): 230 V a.c. 50/60 Hz monofase.
Fig. 1 – Overall dimensions
Caratteristiche tecniche
Overall Dimensions [mm]
Tipo
MAX
Flow
[l/h]
MAX
Pressure
[bar]
Weight
[Kg]
Height Larghezza Profondità
Potenza
Assorbita
[W]
Velocità
Rotazione
[RPM]
Tubo
[ODxID]
[mm]
MyPool
1,6 1,5 1,5 220 131 119 15 30 4 x 7
Liquid ends materials
 1 - Hose: Santoprene®
 2 - Filter: Standard: Polypropylene
 3 - Suction hose: PVC Cristal®
 4 - Discharge hose: Polyethylene
