Cub Cadet 1515 User Manual

31
SECTION 12: SPECIFICATIONS
1515 1517
Capacities
Fuel Tank
3 gallons (11.4 liters) 3 gallons (11.4 liters)
Crankcase (approximately)
4 pints / 64 oz. (1.9 liters) 4 pints / 64 oz. (1.9 liters)
Transmission Case (approximately)
4.9 pints / 78.8 oz. (2.3 liters) 4.9 pints / 78.8 oz. (2.3 liters)
Hydrostatic Transmission
Make and Model
Hydro-Gear 311-0710 Hydro-Gear 311-0710
Gear Ratio
22.2:1 22.2:1
Forward Speed
0 m.p.h. - 5.5 m.p.h. 0 m.p.h. - 5.5 m.p.h.
Reverse Speed
0 m.p.h. - 2.5 m.p.h. 0 m.p.h. - 2.5 m.p.h.
Engine (Air-cooled, 4-cycle, Gasoline, OHV)
Make and Model
Kohler CV15 Kohler CV490
Cylinders
Single Single
Bore
3.55 in. (90 mm) 3.54 in. (90 mm)
Stroke
2.64 in. (67 mm) 3.03 in. (77 mm)
Displacement
26 cu. in. (426 cc) 29.9 cu. in. (490 cc)
Maximum Power @3600 RPM
15 HP (11.2 kW) 17 HP (12.7 kW)
Maximum Torque @2400 RPM
23.8 lbs. ft. (32.3 Nm) 27.7 lbs. ft. (37.6 Nm)
Compression Ratio
8:5:1 8:4:1
Engine Speed (governed)
Low Speed
1200 RPM 1200 RPM
High Speed (no load)
3500 RPM (± 100 RPM) 3500 RPM (± 100 RPM)
Spark Plug Gap
.040 in. (1.0 mm) .040 in. (1.0 mm)
Electrical System
System Voltage
12-volt Negative Ground 12-volt Negative Ground
Battery
270 CCA (sealed) 270 CCA (sealed)
Alternator
15 Amp Regulated 15 Amp Regulated
Fuse (automotive type)
20 Amp 20 Amp
Headlights
Incandescent Incandescent
Brakes
Single Disc (Dry) Single Disc (Dry)
Turf Tires
Front (inches)
15 x 6 x 6 15 x 6 x 6
Rear (inches)
20 x 9 x 8 20 x 9 x 8
Dimensions
Wheelbase
47 in. (119.4 cm) 47 in. (119.4 cm)
Length, over all
68 in. (172.7 cm) 68 in. (172.7 cm)
Width, over all (w/ mower deck - chute up)
45 in. (114.3 cm) 45 in. (114.3 cm)
Height, over all (to top of steering wheel)
43 in. (109.2 cm) 43 in. (109.2 cm)
Ground Clearance
6 in. (15.2 cm) 6 in. (15.2 cm)
Turning Radius
18 in. (46 cm) 18 in. (46 cm)
Weight (approximate)
502 lb (225.9 kg) 504 lb (226.8 kg)
