6 - 5
Cub Cadet 3000
Figure 20.
Figure 19.
Figure 18.
Figure 17.
Using the small screwdriver or similar tool, remove the
dust seal. Caution must be used not to scratch or
damage the dust seals counter bore when removing
the dust seal.
Turn the valve housing over and remove the two
bearing races and thrust bearing.
Carefully remove the centering springs from the
spool.
NOTE: It is not necessary nor recommended to
remove the external ring from the spool.
Carefully remove the spring retaining ring from the
centering springs.
